Vodotěsná SDI Kamera AIDA HD3G-IPC-IP67

Name: Vodotěsná SDI Kamera AIDA HD3G-IPC-IP67
Brand: AIDA Imaging
SKU: ad044
Price: 605.00 EUR
Availability: InStock

SKU: ad044

Vodotěsná Full-HD kamera s výstupem 3G-SDI a krytím IP67 pro náročné vnitřní i venkovní nasazení. Osazena 1/2.8″ Sony CMOS senzorem se snímáním 1080 60p.

Full HDCSSDI

From 605 €

Price incl. 21% VAT

excl. VAT 500 €

Vodotěsná SDI Kamera AIDA HD3G-IPC-IP67—

605 €excl. VAT 500 €

In stock at our supplier — ships within 2–3 business days

Key specs

Resolution: Full HD @ 60 fps
Sensor size: 1/2.8"
Mount: CS
Interface: SDI

Authorized distributor — full manufacturer warranty
Shipped from Brno across the EU
B2B purchase on invoice

Need advice or a quote? +420 910 124 151 · [email protected]

Product description

LINK TO MANUFACTURER'S WEBSITE

MAIN FEATURES

• Full-HD 1/2.8" Sony Progressive Scan CMOS sensor capable of 1080 60p over 3G-SDI
• VISCA over IP compatible with hardware and software solutions using this protocol (VISCA UDP, SONY VISCA over IP)
• Versatile design with tripod mounts for easy and unique shots
• PoE+ compatible with adapter (included in the box)
• IP67 rating
• CS-Mount lens
• Compact size and rugged design enable all types of video streaming
• Ideal for indoor and outdoor shots in new and existing workflows

SPECIFICATIONS

VIDEO

Image Sensor:	1/2.8" Progressive CMOS
Sensor Size:	5.640mm x 3.216mm (16:9)
Effective Pixels:	Horizontal: 1920, Vertical: 1080
Pixel Size:	2.9 μm (H) x 2.9 μm (V)
Resolution:	1080p, 1080i, 720p
Resolution Rate:	1080 60p/59.94/50p/30p/29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p
Output:	3G-SDI
Color Space:	4:2:2 (YCbCr) 10bit
Min. Illumination:	0.2Lux (day), 0.1Lux (night)
White Balance:	Auto & Manual (9000 - 11,000 K)
Audio Input:	3.5mm TRS Stereo input, Embedded via SDI

LENS

HD3G-IPC-IP67:

CS mount 4mm lens
HFOV: 80°

PHYSICAL PARAMETERS

Camera Control:	RJ45 (VISCA over IP) RS485 (Serial VISCA)
Operating Temperature:	-10°C to 50°C
Power:	12VDC (+9 - +15VDC) (PoE adapter included)
Power Consumption:	6W MAX

Specifications are subject to change without prior notice.
