Dante AV-H Kamera AIDA HD-AVH-100A

SKU: ad048

Jedna z nejlevnějších SDI kamer na trhu podporující tri-level sync (genlock)

Full HDCSHDMIIP
From 968 €

Price incl. 21% VAT

excl. VAT 800 €
Dante AV-H Kamera AIDA HD-AVH-100A
968 €excl. VAT 800 €
In stock at our supplier — ships within 2–3 business days
Key specs
Resolution
Full HD @ 60 fps
Sensor size
1/2.8"
Mount
CS
Interface
HDMI · IP
  • Authorized distributor — full manufacturer warranty
  • Shipped from Brno across the EU
  • B2B purchase on invoice

Need advice or a quote? +420 910 124 151 · [email protected]

Product description

This POV camera speaks Dante®!

The HD-AVH-100A is the world's first Dante AV-H-ready POV camera. Seamlessly integrate it into the Dante audiovisual ecosystem with a simple license activation and unify your video and Dante audio in one efficient workflow. With a versatile CS mount lens, built-in PoE+, HDMI output, and IP streaming (RTSP, RTMP, or SRT), this compact camera is made for environments where Dante already reigns – from live events to churches and houses of worship.

LINK TO MANUFACTURER'S WEBSITE

MAIN FEATURES

  • • Full HD 1080p 1/2.8” Progressive Scan CMOS sensor capable of capturing up to 60fps
  • • Built-in PoE+ for simplified power and data transmission over a single cable.
  • • Simultaneous output via Dante® AV-H, HDMI, and IP streams.
  • • The world's first Dante®-ready POV camera, enabling easy integration into Dante AV-H workflows after a simple license activation.
  • • Rugged and versatile design with a 1/4”-20 mounting thread for easy installation.
  • • Supports multiple IP streaming protocols, including RTSP, RTMP, and SRT.
  • • Flexible CS mount for customizable field-of-view options.
  • • Compact and lightweight design – ideal for fixed installations, live events, and mobile productions.

SPECIFICATIONS

VIDEO

Image Sensor: 1/2.8” Progressive CMOS
Effective Pixels: Horizontal: 1920, Vertical: 1080
Pixel Size: 2.9 μm (H) x 2.9 μm (V)
Resolution: 1080p, 1080i, 720p
Frame Rates: 1080 60p/59.94/50p/30p/25p/24p
1080 60i/59.94i/50i
720 60p/59.94p/50p
Output: DANTE AV-H (license purchase required) / HDMI / IP
Color Space: 4:2:2 (YCbCr) 10bit
Min. Illumination: 0.2Lux (Day), 0.1Lux (Night)
White Balance: Auto & Manual (9,000 - 11,000 K)

LENS

Lens: 5MP 4mm CS Mount lens
HFOV: 72°

AUDIO

Audio Embedding: Via IP streams ONLY
Input: 3.5mm Line Input

PHYSICAL PARAMETERS AND CONTROL

Control Protocol: Serial VISCA, VISCA over IP
Camera Control: Protocol: RS485, RJ45
Operating Temperature: 0°C - 40°C
Dimensions: 81mm x 50mm x 50mm
Weight: 453 g
Power: 12VDC (+9 - +15VDC) (with PoE+ adapter)

Specifications are subject to change without prior notice.
