POV NDI SDI Kamera AIDA HD3G-NDI-200
SKU: ad040Kompaktní Full-HD POV kamera s 1/2.8″ CMOS senzorem podporující 3G-SDI a NDI HX výstup. Umožňuje snadnou integraci do IP workflow a přímý streaming přes webové rozhraní.
Full HDNDI®CSSDIIPFrom 774,40 €
Price incl. 21% VAT
excl. VAT 640 €POV NDI SDI Kamera AIDA HD3G-NDI-200—
774,40 €excl. VAT 640 €
In stock at our supplier — ships within 2–3 business days
Key specs
- Resolution
- Full HD @ 60 fps
- Sensor size
- 1/2.8"
- Mount
- CS
- NDI
- Yes
- Interface
- SDI · IP
- Authorized distributor — full manufacturer warranty
- Shipped from Brno across the EU
- B2B purchase on invoice
Need advice or a quote? +420 910 124 151 · [email protected]
Product description
LINK TO MANUFACTURER'S WEBSITE
MAIN FEATURES
- • Full-HD 1/2.8" Progressive Scan CMOS sensor capable of 1080 60p NDI® HX and 3G-SDI video
- • Accessible web interface for direct streaming to social platforms and image parameter control over IP
- • Versatile and discreet design perfect for elegant multi-level shooting in most scenarios
- • OSD breakout cable provides power or control via serial RS485 communication
- • Flawless transmission of multi-channel embedded audio over NDI® HX2
- • Ideal for upgrading existing 3G-SDI workflows to IP / NDI® HX
SPECIFICATIONS
VIDEO
| Image Sensor: | 1/2.8" Progressive CMOS |
| Effective Pixels: | Horizontal: 1920, Vertical: 1080 |
| Pixel Size: | 2.9 μm (H) x 2.9 μm (V) |
| Resolution: | 1080p, 1080i, 720p |
| Resolution Rate: | 1080 60p/59.94/50p/30p/29.97p/25p/24p/23.98p 1080 60i/59.94i/50i 720 60p/59.94p/50p/30p/29.97p/25p |
| Output: | 3G-SDI, RJ45, NDI® HX2 |
| IP Rate: | 1920 x 1080 @ 3~60 1280 x 720 @ 3~60 1024 x 576 @ 3~60 620 x 360 @ 3~60 |
| Color Space: | 4:2:2 (YCbCr) 10bit |
LENS
| Lens: | C/CS Mount (default 4mm HD lens) |
AUDIO
| Input: | 3.5mm TRS Stereo Audio Port |
| Sample Rate: | 16/24/32 Bits |
PHYSICAL PARAMETERS
| Camera Control: | Protocol: VISCA RS485, VISCA Over IP Control: OSD button or Web UI |
| Operating Temperature: | 0°C - 40°C |
| Dimensions: | 54mm x 54mm x 127mm (with default 4mm lens) |
| Power: | 12VDC (+9 - +15VDC)/ POE |
NDI® is a registered trademark of Newtek, Inc.
Specifications are subject to change without prior notice.
