Vodotěsná NDI Kamera AIDA HD-NDI3-IP67
SKU: ad033Vodotěsná HD kamera s krytím IP67 a rozhraním NDI HX3 pro přenos videa až 1080p 60fps po síti. Podporuje PoE+ a nabízí webové rozhraní pro vzdálené ovládání.
Full HDNDI®CSIPPrice incl. 21% VAT
excl. VAT 960 €- Resolution
- Full HD @ 120 fps
- Sensor size
- 1/3"
- Mount
- CS
- NDI
- Yes
- Interface
- IP
- Authorized distributor — full manufacturer warranty
- Shipped from Brno across the EU
- B2B purchase on invoice
Need advice or a quote? +420 910 124 151 · [email protected]
LINK TO MANUFACTURER'S WEBSITE
MAIN FEATURES
- • Full-HD 1/3" Progressive Scan CMOS sensor capable of capturing 1080p 120fps over NDI®|HX
- • HX 3 compatible camera with output of up to 1080p 60fps at 60mb, 4 times more than HX!
- • Accessible web interface for direct streaming to social platforms and image parameter control over IP
- • Versatile design with top and bottom tripod mounts for unique shots
- • The camera supports PoE+. A single cable is all you need for power, control, and video!
- • Compact size and rugged design enable all types of video streaming
- • Small tally light on the front of the camera to indicate live broadcasting
- • IP67-rated waterproofing for protection against outdoor elements and brief submersion in water!
SPECIFICATIONS
VIDEO
| Image Sensor: | 1/3" Progressive CMOS |
| Effective Pixels: | Horizontal: 1920, Vertical: 1080 |
| Pixel Size: | 2.13 μm (H) x 2.13 μm (V) |
| Resolution: | 1080p, 1080i, 720p |
| Resolution Rate: | NDI HX ONLY: 1080 120p, 100p HX 3 and others: 1080 60p/59.94/50p/30p/29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p |
| Output: | IP (NDI HX3/SRT/RTMP/RTSP) |
| Color Space: | 4:2:2 (YCbCr) 10bit |
| Min. Illumination: | 0.2Lux (day), 0.1Lux (night) |
| White Balance: | Auto & Manual (9000 - 11,000 K) |
LENS
| Lens: | 5MP 4mm CS Mount HD Lens |
| FOV: | 86° |
AUDIO
| Audio Embed: | Embedded via HDMI and IP streaming |
| Input: | 3.5mm Line Input |
WEATHERPROOFING
| IP Rating: | IP67 - Protection against moisture and dust |
PHYSICAL PARAMETERS
| Camera Control: | Protocol: VISCA Over IP |
| Operating Temperature: | 0°C - 40°C |
| Dimensions: | 120mm x 53mm x 53mm |
| Weight: | 800g |
| Power: | 12VDC (+9 - +15VDC), PoE+ (IEEE802.3at standard) |
NDI® is a registered trademark of Newtek, Inc.
Specifications are subject to change without prior notice.
