Voděodolná NDI Kamera AIDA HD-NDI-VF
SKU: ad031IP56 NDI|HX kamera s překvapivě kvalitním vstavaným varifokálním objektivem
Full HDNDI®IPPrice incl. 21% VAT
excl. VAT 615 €- Resolution
- Full HD @ 60 fps
- Sensor size
- 1/3"
- NDI
- Yes
- Interface
- IP
- Authorized distributor — full manufacturer warranty
- Shipped from Brno across the EU
- B2B purchase on invoice
Need advice or a quote? +420 910 124 151 · [email protected]
LINK TO MANUFACTURER'S WEBSITE
MAIN FEATURES
- • Full-HD 1/3" Progressive Scan CMOS sensor capable of 1080 60p NDI®|HX video
- • Accessible web interface for direct streaming to social platforms and image parameter control over IP
- • Versatile design with top and bottom tripod mounts for unique shots
- • PoE+ compatible with adapter (included in the box)
- • Custom varifocal lens with IP54 rating providing a 120° wide and 36° telephoto field of view for the perfect shot
- • Weatherproof design provides additional protection against the elements
- • Compact size and rugged design enable all types of video streaming
- • Ideal for outdoor shots in any new or existing NDI®|HX setup
SPECIFICATIONS
VIDEO
| Image Sensor: | 1/3" Progressive CMOS |
| Sensor Size: | 5.346mm x 3.003mm (16:9) |
| Effective Pixels: | Horizontal: 1920, Vertical: 1080 |
| Pixel Size: | 2.75 μm (H) x 2.75 μm (V) |
| Resolution: | 1080p, 1080i, 720p |
| Resolution Rate: | 1080 60p/59.94/50p/30p/29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p |
| Output: | IP (NDI|HX/SRT/RTMP/RTSP) |
| Color Space: | 4:2:2 (YCbCr) 10bit |
| Min. Illumination: | 0.2Lux (day), 0.1Lux (night) |
| White Balance: | Auto & Manual (9000 - 11,000 K) |
LENS
| Lens: | 2.8mm ~ 12mm custom lens |
| FOV: | Wide: 120° Telephoto: 36° |
STANDARD
| IP Protocol: | UDP|IP, RTSP|RTMP, SRT, NDI|HX |
PHYSICAL PARAMETERS
| Camera Control: | Protocol: VISCA Over IP |
| Operating Temperature: | 0°C - 40°C |
| Dimensions: | 73mm x 41mm x 41mm (with attached lens) |
| Weight: | 454g |
| Power: | 12VDC (+9 - +15VDC) (PoE adapter included) |
NDI® is a registered trademark of Newtek, Inc.
Specifications are subject to change without prior notice.
